20v High Temp Battery 3000Ah Solar Energy Storage Battery

Product Categories
Jiangsu CASI Solar Co., Ltd.
Contact Now

20v High Temp Battery 3000Ah Solar Energy Storage Battery

Brand Name : Licloud

Model Number : GFMH

Certification : CE

Place of Origin : China

MOQ : 10 pcs

Price : Negotiable

Payment Terms : T/T, Western Union, L/C

Supply Ability : 10000 pcs per week

Delivery Time : 15-20 working days

Packaging Details : According to customer's requirement

Product name : High Temp Battery

Battery Voltage : 12V/2V

Capacity : 300-3000Ah

Dimensions : 396*110*287mm

Weight : 31.1kg

Battery Cover and exhaust tether Structure : Valve regulated sealed battery

Output Type : Terminal output

Application : High Temperature Area

Charge State : Maintenance-free battery

Warranty : 3 Years

Contact Now

High Temp Battery 2V 12V Plateau Energy Storage High Temperature Area

Description

High Temp Battery is a new product independently developed by CASI Solar for high temperature use environment, which is an original innovation and major breakthrough in the field of domestic valve regulated sealed gel battery, solving the traditional problem of high temperature impact on the performance and life of valve regulated sealed gel battery, increasing the working temperature of gel battery from 25℃ to 35℃ and maintaining the same life level.

Battery Series Voltage(V) Capacity Weight(KG) Dimension(MM)
Height Length Width
GFMH800-2 2 800 50.5 366 411 175
GFMH1000-2 2 1000 61.5 365 475 175
GFMH1500-2 2 1500 97 378 401 350
GFMH2000-2 2 2000 123 383 491 351
GFMH3000-2 2 3000 182 383 712 355
GFMH100-12 12 100 31 286 395 110
GFMH150-12 12 150 48 314 550 110
GFMH200-12 12 200 58 316 561 125

20v High Temp Battery 3000Ah Solar Energy Storage Battery

Technical Parameters

  • Product name: High temp battery
  • Capacity range (C10): 300Ah~1000Ah (25°C).
  • Voltage rating: 2V/12V.
  • Long design life: 10 years design life (35°C).
  • Wide range of applicable temperatures: -20~75°C.
  • Wide applicable temperature range: -20~65℃.
  • Special corrosion-resistant alloy and plate grid structure design.

Features

  • Product name: High temp battery
  • Low resistance embedded copper core front end for easy installation Special multi-alloy grid to extend battery life
  • Adopting high-strength, heat-resistant shell material to ensure that the shell will not bulge, deform and crack under high temperature conditions.
  • Adopting special corrosion-resistant alloy and plate grid structure design, which improves the corrosion resistance life of the plate grid under high temperature.

Advantages

  • Product name: High temp battery
  • Can be used to increase air conditioning operating temperature to 35°C or for direct fan cabinets, reducing operating costs
  • Long service life at high temperature, working under high temperature of 35℃ for a long time, it can reach the service life of floating charge of conventional AGM battery at 25℃.
  • 10 years design life at 35°C
  • Wide operating temperature range, can work at -40 to +65°C, the limit temperature reaches 80°C.

Application

  • Product name: High temp battery
  • Base stations in high-temperature environments, areas with a year-round ambient temperature of 30°C and above
  • Base stations in areas with frequent power outages
  • Base stations in normal temperature areas
  • Base stations in remote areas.

Compliant standards

  • GB/T 19638.2-2014
  • GB/T 22473-2008
  • YD/T799-2010
  • YD/T2657-2013
  • IEC61427-2013

Product Tags:

3000Ah High Temp Battery



20v High Temp Battery



3000Ah solar energy storage battery


Quality 20v High Temp Battery 3000Ah Solar Energy Storage Battery for sale
